电缆桥架主要技术指标

电缆桥架主要技术指标
一、电缆桥架结构要求
电缆槽盒：采用无孔托盘式，带有可移动盖子的结构要求，垂直和水平方式敷设电线电缆。
电缆托盘：采用有孔托盘式，没有盖子，敷设较多较大强电电缆。
电缆梯架：采用梯式敷设大电缆电力。
二、电缆槽盒
需给电缆槽盒及盖板设置压盖板及锁扣。
设置终端栏板给终端电线槽。
确保有可靠的电气连接并接地，对于金属电缆槽盒。
三、电缆托盘
电缆桥架厂家需提供充足的供地用铜编制带，保证电缆桥架接头处都有接地点。
电缆桥架厂家需配置连接片给电缆托盘。
电缆桥架厂家需配备相同材质的电缆托盘盖板。
四、电缆梯架
电缆桥架厂家需提醒不同电压、不同用途的电缆不宜架设在同一层，，实在没办法，也要用隔板隔开。

Main technical indexes of cable bridge

1. Requirements for the structure of cable bridge

Cable slot box: with no hole tray type, with movable lid structural requirements, vertical and horizontal way laying wire and cable.

Cable tray: it has a hole tray, no lid, and more large strong cable.

Cable ladder rack: ladder type large cable power supply.

Two, cable slot box

It is necessary to install the pressure cover plate and the lock catch for the cable slot box and the cover plate.

Set the terminal plate to the terminal wire slot.

Ensure reliable electrical connections and grounding for metal cable box boxes.

Three, cable tray

Cable bridge manufacturers need to provide adequate copper supply for the ground to ensure that there are grounding points at the junction of the cable bridge.

Cable tray manufacturers need to configure connecting pieces to cable tray.

The cable tray manufacturers shall have the same material cable tray cover plate.

Four, cable ladder

Cable bridge manufacturers need to remind that cables with different voltage and different uses are not suitable for erection on the same floor.
